Marine Switches & Sockets

Category： Marine Switches & Sockets
Product description：Marine-grade switches and sockets for onboard electrical systems. Waterproof, corrosion-resistant, and IP-rated. Includes rocker switches, toggle switches, and AC/DC power sockets.
INQUIRY EMAIL

Marine Switches & Sockets

Weatherproof, Corrosion-Resistant Electrical Controls for Marine Environments

Product Overview:

Our marine switches and sockets are precision-engineered for the unique demands of the marine environment – where saltwater spray, humidity, UV exposure, vibration, and temperature extremes quickly destroy standard domestic electrical components. Constructed from marine-grade materials including 316 stainless steel, nickel-plated brass, and UV-stabilised thermoplastics, with neoprene or silicone sealing systems, these components deliver reliable, safe, and long-lasting service in all onboard locations – from dry interior cabins to exposed decks, cockpits, flybridges, and engine rooms. The range includes toggle switches, rocker switches, push buttons, selector switches, dimmers, indicator lights, AC shore power inlets and interior outlets, DC accessory sockets (cigarette lighter, Merit/Hella, USB), and data sockets (Ethernet, antenna, HDMI).

Switch Functions:

On-Off (2 positions): Simple on/off
On-On (2 positions): Selects between two circuits
On-Off-On (3 positions): Center off, each side selects different circuit
Momentary (spring return): (On)-Off – for horn, trim tabs, bilge pump test
Momentary both sides: (On)-Off-(On) – spring return from both positions

Ratings:

Standard: 10A at 12V DC, 5A at 24V DC (resistive load)
Heavy duty: 20A at 12V DC, 10A at 24V DC
Motor loads: Derate to 1/2 to 1/3 of resistive rating due to inductive surge

Sealing Options:

Booted toggle: Rubber or silicone boot covering base and lever – achieves IP66 or IP67. Essential for deck or cockpit installation.
Unbooted: Interior, dry locations only
