Product Name: Marine Winches – For Yachts

Engineered specifically for the luxury yacht and superyacht industry, our marine winches deliver reliable, high-performance line handling for anchoring, mooring, docking, and sail control. Designed to withstand continuous saltwater exposure, heavy loads, and demanding sea conditions, each winch combines robust power, precise control, and elegant styling that complements the yacht’s sophisticated exterior.

Material Excellence:

• Drum and housing: Stainless Steel Grade 316L or lightweight, hard-anodized aluminum

• Chrome-plated bronze or duplex stainless steel options for ultra-premium builds

• Finishes: Mirror polish, satin (brushed), matte black PVD, or custom powder coating

• Corrosion protection: Multi-layer epoxy or marine-grade coating on internal components

• Fasteners: Grade 316 stainless steel throughout

Winch Types Available:

• Anchor Winches (Windlasses): Vertical or horizontal configuration; single direction or dual direction (up/down); manual or hydraulic chain stopper integration

• Mooring Winches: Capstan or drum style; single or double drum; automatic self-tailing for effortless line handling

• Towing Winches: Heavy-duty, high-line pull with dynamic braking and level-wind mechanism

• Sail Control Winches: Manual or electric; single or two-speed (multi-speed options); self-tailing or non self-tailing for racing or cruising yachts

• Cargo / Deck Winches: General purpose for tender lifting, passerelle deployment, or dive platform operations

Anchor Winches (Windlasses) – Key Features:

• Chain size compatibility: 6mm to 20mm (DIN, ISO, or BBB chain types)

• Maximum pull: 500 kg to 5,000+ kg (model dependent)

• Gypsy and capstan combination for chain and rope handling

• Automatic chain stripper and wear plate for chain management

• Manual emergency override (hand crank or hydraulic backup)

• Integrated chain counter and remote controls (wired or wireless)

• Free-fall option for rapid anchor deployment

Mooring Winches – Key Features:

• Line pull capacity: 500 kg to 10,000 kg

• Line speed: 5 to 30 m/min (variable depending on load)

• Drum capacity: Up to 200m of 20mm diameter rope

• Automatic self-tailing mechanism for jam-free, hands-off line handling

• Level-wind mechanism for even rope layering on drum

• Dynamic braking and load holding for safety during docking

Sail Control Winches – Key Features:

• Power ratio (mechanical advantage): 1:1 to over 50:1 depending on gear configuration

• Two-speed or three-speed gearbox for fast trimming or high-power sheeting

• Self-tailing jaw for single-handed sail handling

• Stripping ring and skirt to prevent line overrides

• Electric or hydraulic drive with smooth, progressive control

• Manual backup option for emergency or low-power situations

Marine-Specific Engineering:

• IP66 or IP67 sealed construction – protected against heavy seas and jet washing

• ISO 9227 salt spray tested: 1,500+ hours without corrosion

• Operating temperature: -20°C to +70°C

• Dynamic braking and overload protection (automatic cut-off or slip clutch)

• Low-noise gearbox (helical or planetary) for quiet operation – essential for luxury yachts

• Corrosion-resistant bearings and seals throughout

• Emergency manual operation via crank handle or hydraulic hand pump

Power & Control Options:

• Electric winches: 12V, 24V, 48V DC or 110V/230V AC with soft-start and variable speed control

• Hydraulic winches: Integrated with yacht’s hydraulic power pack; precise speed and torque control

• Manual winches: Geared for mechanical advantage, with removable handle

• Control interfaces: Waterproof push-button panels, wireless remote (radio frequency), helm station integration, or touchscreen yacht management system

• Chain counter display: Wireless or wired with depth and scope readout

Safety & Class Approvals:

• ABYC (American Boat & Yacht Council) standards for anchoring and mooring equipment

• ISO 4568: Small craft – anchor winches

• Lloyd’s Register, DNV, ABS, or RINA type approval available

• CE marked for recreational craft directive (RCD)

Typical Yacht Applications:

• Primary anchor handling (bow windlass)

• Secondary stern anchor winch

• Mooring lines (spring, bow, stern, midship)

• Passerelle (gangway) deployment

• Tender lifting and recovery

• Sail trim (mainsheet, jib sheets, halyards)

• Diving platform or tender garage operations

Package Includes (Per Winch Unit):

• Winch assembly with drum/gypsy and housing

• Electric motor or hydraulic motor (if powered)

• Control system (push-button panel or wireless remote)

• Mounting bracket and fasteners (Grade 316 stainless steel)

• Installation, operation, and maintenance manual

• Spare parts kit (seals, bearings, fasteners)

Optional Upgrades:

• Dual-station controls (bow and helm or helm and remote)

• Chain counter with depth and scope display

• Emergency hydraulic hand pump or manual crank kit

• Stainless steel chain stripper and wear plate

• Custom powder coat or PVD finish to match yacht hardware

• Integrated rope drum for mixed chain/rope rode

• Load cell and tension display for precise anchoring

Choose our marine winches for your yacht to combine raw power with refined control. From a silent, smooth anchor deployment at dawn to the effortless docking of a superyacht in a crowded marina – every winch is engineered to perform flawlessly while maintaining the elegance and sophistication expected by discerning yacht owners.
